Are you a proud owner of a GM vehicle equipped with the 2.4 liter Ecotec motor? Or perhaps you're considering purchasing one? While this engine has gained popularity for its fuel efficiency and performance in various models, it's not without its share of issues that owners and potential buyers should be aware of. In this blog post, we'll get into some of the common problems associated with the Chevy 2.4 liter Ecotec motor, providing insights to help you make informed decisions.
This motor was developed by General Motors with efficiency and fuel economy in mind for daily driving applications. It is an inline 4 cylinder that produces 164 - 182 hp and about 172 lb-ft of torque. It features direct injection, dual overhead cams, and variable valve timing. It can be found in cars such as the Chevrolet Captiva, Chevrolet Equinox, GMC Terrain, Buick Verano (CX/CXL), and Buick Regal.
While it is definitely an efficient motor, there are some significant issues that have been reported by numerous owners over time. Some of the main issues this motor can develop include oil consumption and timing issues, which can lead to a plethora of problems. It is also known to have issues with the PCV system and rear main seal.
In simpler terms, this motor is known to burn a lot of oil. The recommended oil change is 7,500 miles, similar to many newer cars on the road. However, many people have noticed cars with this motor burning up to a quart every 1,000 miles, sometimes even more. Now if the car burns an average of 1 quart of oil every 1,000 miles, has an oil capacity of 5 quarts, and the oil change interval is every 7,500 miles, then you’re burning more oil within the oil change interval than the car has the capacity for. So it is CRUCIAL that you regularly check and top off the engine oil with cars that feature these motors.
GM uses lightweight aluminum pistons in these motors for less reciprocating mass inside the engine which enhances efficiency. They also use thinner, lower-tension piston rings (or oil rings as some may know) that don’t always work as effectively as they should. The rings wrapped around the piston should keep oil out of the combustion chamber and maintain the motor's compression as the piston moves. However, because thinner rings are used they tend to compress easier and wear out faster, forming gaps and letting oil sneak past into the combustion chamber where it will burn. The gaps will also cause the motor to lose some of its compression and run less efficiently.
A poor design in the PCV system can also contribute to the oil consumption issue. The PCV or positive crankcase ventilation is used to recycle combustion vapors. It pulls the vapors out of the crankcase back through the intake manifold and into the combustion chamber. The problem with these motors is that they also pull oil through the PCV and send it to the combustion chamber, where it should not be. So basically, the system that is meant to only recycle vapors also pulls oil from one place in the motor and puts it into another place where it can burn. The other issue with the PCV on these cars is that the valve in the system can get clogged, which brings us to our rear main seal issue. When the valve gets clogged, it can no longer pull the vapors out of the crankcase, resulting in more pressure. The extra pressure helps weaken the rear main seal, which can only take so much before it will eventually start to leak. Unfortunately, the rear main is one of the bigger seals in the motor, so it can become a pretty nasty leak that needs to be taken care of quickly.
The timing issues the 2.4 Ecotec has can also be linked to the oil consumption issue in some cases. Oil pressure helps keep the chains tensioned. With these cars consuming so much oil, if owners don’t keep it topped off and the oil level is low, then the oil pressure is low too. Even though there are springs and tensioners in the system to maintain optimal tension, without the help of oil pressure the system is more prone to premature wear and failure. The chain can become loose, tensioners and guides can wear and break, the chain can skip teeth on the sprocket or break and cause catastrophic engine damage. None of it is good and it usually isn’t cheap either. Some of the telltale signs of issues with the timing system include a slapping/rattling noise, poor engine performance, such as rough idling or sluggish acceleration, or a check engine light. It is important to mention that these parts do wear out and fail over time in any vehicle. While the premature timing issues this motor experiences can often be linked to oil consumption, it is not always the case.
While the 2.4 Ecotec offers good fuel efficiency and performance, it's essential to stay proactive about maintenance and be aware of these potential issues. If you currently own a vehicle with this motor or are considering purchasing one, we recommend changing the oil every 4,500 miles, possibly even sooner depending on how many miles you put on it and your driving habits. Be sure to use the correct oil grade, and check the oil level often. Some technical service bulletins were released about oil consumption and timing chains which will be linked below at the end of this article for more information. Monitoring oil consumption between changes can help detect any abnormal usage early on. By staying informed, performing regular maintenance, and addressing any concerns promptly, you can help prevent these issues and increase the likelihood of having a long and trouble-free ownership experience. Following these steps with any vehicle will help you get the most out of it. If you notice any of the signs mentioned, it’s advisable to consult a qualified mechanic as soon as possible. We hope this blog post helps owners have a better understanding of the different possibilities they could be faced with and how to take action to avoid them. Give us a call at 973-366-3777 or send us an email at [email protected] if you have any questions!
Technical Service Bulletins:
https://static.nhtsa.gov/odi/tsbs/2016/MC-10119011-9999.pdf
https://static.nhtsa.gov/odi/tsbs/2016/SB-10090368-2280.pdf
https://static.nhtsa.gov/odi/tsbs/2020/MC-10171426-9999.pdf
